PU010 adhesive is ideal for quick installation of insulation and acoustic panels, SATE and roof insulation. Suitable for use on many different substrates including masonry, concrete, wood and metal.
CHARACTERISTICS
- An easy-to-use alternative to dry wall mortars and adhesives
- Ideal for joining drywall, insulation and SATE
- Forms a high-strength bond after just 40 minutes
- Expands to fill gaps, cavities and uneven surfaces
- Compatible with a wide range of construction supports
- Charging time after approximately 3 hours
- Fast curing, skin formation in 10 minutes
- No subsequent expansion or contraction
SPECIFICATIONS
|
Characteristics |
Rule |
Classification |
|
Reaction to fire |
DIN 4102-1 |
B2/B1 |
|
Foam type |
N.B.S. |
|
|
Quality |
EIFS |
|
|
Component system |
Single component |
|
|
Propellants |
Yeah |
|
|
Aerosol limit temperature |
10ºC – 30ºC |
|
|
Ideal aerosol temperature |
20ºC |
|
|
Ambient limit temperature |
5ºC – 35ºC* |
|
|
Density |
LAB 015 |
15 - 25 |
|
Skin formation (min) |
FEICA TM 1014 |
10 |
|
Time to cut (min) |
FEICA TM 1005 |
35 |
|
Load capacity (hour) |
3 |
|
|
Performance |
FEICA TM 1003 |
30l |
|
Thermal conductivity (mW/mK) |
EN 12667 |
36 |
|
Elongation at break (%) / dry |
FEICA TM 1018 |
14 |
|
Compression strength @ 10% (kPa) / dry |
FEICA TM 1011 |
44 |
|
Compression strength @ 10% (kPa) / wet |
32 |
|
|
Shear strength (kPa) / dry |
FEICA TM 1012 |
51 |
|
Temperature resistance (long term) (°C) |
-40 ºC – 90 ºC |
|
|
Temperature resistance (short term) (°C) |
-40 ºC – 130 ºC |
|
|
VOC (%) |
17.49 |
|
|
VOC (g/l) |
180.00 |
|
|
Conservation |
24 months |
APPLICATION TIPS
- Shake the bottle vigorously at least 20 times.
- Remove the protective cap from the canister and place the upper end into the illbruck PU foam gun adapter.
- Spray a bead of illbruck PU010 adhesive foam around the perimeter and center back of the insulation material.
- Always handle the canister upright for best results and make sure the valve is facing downward.
- Move the panel into place and press firmly to ensure good contact. Hold it in position for 2-3 minutes. Heavy panels may require additional support during curing.
